din f4 high mounting pad ball valve

the release date：[2017-08-07] hits

德标法兰球阀设计标准：

设计标准design: din 3357 en 12516-1
壁厚标准wall thickness: asme b16.34 en 12516-1
防火标准fire safe: api 307 iso 10497
结构长度face to face: din 3202
法兰标准end flange: din en 1092-1
检测标准/inspection & testing: din 3230 en 12266

德标法兰球阀产品特点:

阀杆带有防静电设置 ante-static devices for ball-stem-body
阀杆带有防脱出装置设计 blow-out proof stem
钢球球槽上有泄压孔设计 pressure balance hole in ball slot
采用iso 5211 支架安装执行器平台设计
built in iso 5211 bracket mount for easy automation

德标法兰球阀外形尺寸表：
单位：mm
size	pn	d	l	r	c	d	h	h1	e	f	t	□p	ø a	øb	n	øx	iso 5211
dn15	10-40	15	115	45	65	95	78	34	150	2	14	11	42	4	4	14	f04
dn20	10-40	20	120	58	75	105	80	35	150	2	16	11	42	4	4	14	f04
dn25	10-40	25	125	68	85	115	88	45	150	2	16	11	42	4	4	14	f04
dn32	10-40	32	130	78	100	140	100	50	170	2	16	14	50	5	4	18	f05
dn40	10-40	38	140	88	110	150	122	60	230	3	16	17	70	6	4	18	f07
dn50	10-40	50	150	102	125	165	130	68	230	3	18	17	70	6	4	18	f07
dn65	10-16	65	170	122	145	185	148	86	230	3	18	17	70	6	4	18	f07
dn80	10-16	78	180	138	160	200	167	96	305	3	20	22	102	8	8	18	f10
dn100	10-16	100	190	158	180	220	188	117	305	3	20	22	102	8	8	18	f10
dn125	10-16	125	325	188	210	250	246	141	500	3	22	22	125	10	8	18	f12
dn150	10-16	150	350	212	240	285	288	172	650	3	22	27	125	10	8	22	f12
dn200	10-16	200	400	268	295	340	329	213	850	3	24	27	125	10	12	22	f12
dn250	10-16	250	450	320	355	405	396	255	1400	3	26	36	140	14	12	26	f14
