jis high mounting pad ball valve 10k

the release date：[2017-08-07] hits

scs13 starring scs13a standard ball ball scs14 scs14

product information japanese standard flange ball valve

jis flanged ball valve characteristics: the feature:
. 1, full bore, floating / fixed ball. 1, full port, or trunnion mounte floating type
2, bolted flange 2, bolted bonnet
. 3, anti-out stem 3, blow out proof stem
4, fire and anti-static structure
5, the structure of the standard 5, structure improve on jis
6, opening and closing positioning mechanism 6, opening and closing position
7, available with wormgear operator
8, standard flange connection 8, fanged ends

standard specification for ball valves for ball valves

product specification

product

specification

design specification

design spec

structure length

face to face

connecting flange

flange end

test and test

test & check

product identification

marking

supply specification

supply

api608

asme b16.10

ansi b16.5

api598

mss sp-25

api608

api6d

standard specification for ball valves for ball valves

standard high standard platform ball valve

design basis	standard series	american standard series
design standards	bs5351	ap16d	ansi b16.34
flange connection structure length	jis b2002	ap16d	ansi b16.10
structure length (welding)	-	ap16d	ansi b16.10
connecting flange	jis b2212 b2214	ansi b16.5, b16.47
butt end	-	ansi b16.25
test and test	jis b2003	ap16d	ap1598

high standard ball valve parameters

design basis	standard series	american standard series
design standards	bs5351	ap16d	ansi b16.34
flange connection structure length	jis b2002	ap16d	ansi b16.10
structure length (welding)	-	ap16d	ansi b16.10
connecting flange	jis b2212 b2214	ansi b16.5, b16.47
butt end	-	ansi b16.25
test and test	jis b2003	ap16d	ap1598

日标高平台球阀主要零部件材料main part material

零件名称	零部件材料 part material										part name
阀体/阀盖	a216-wcb	a105		a352-lc8	a351-cf8		a351-cf8m	a351-cf3		a351-cf3m	body/bonnet
球体	a182-f304	a182-f304		a182-f304	a182-f304		a182-f316	a182-f304l		a182-f316l	ball
阀杆	a182-f6a	a182-f6a		a182-f6a	a182-f304		a182-f316	a182-f304l		a182-f316l	stem
阀座	a105				a182-f304		a182-f316	a182-f304l		a182-f316l	seat ring
密封圈	ptfe				r.ptfe						seat
填料	聚四氟乙烯/ptfe fpm				聚四氟乙烯/ptfe fpm						packing
垫片	18-8柔性石墨/18-8/flexible graphite 聚四氟乙烯/ptfe fpm										gasket
螺栓	a193-b8					a193-b8m					bolt
适用温度	-29~121℃		-40~121℃			-40~121℃			-40~121℃		suitable temp
适用介质	水、油品、蒸汽 water、oil、steam					硝酸类 nitric acid			醋酸类 acetic acid		suitable medium

日标高平台球阀主要外形和连接尺寸main external and connection

日标高平台球阀主要外形和连接尺寸 main extemal and connection dimension 单位 unit:mm

type	nps	dn	jis 10k
type	in	a	l	d	d1	z-φd
jis ball valve	1/2"	15	108	95	70	4-φ15
	3/4"	20	117	100	75	4-φ15
	1"	25	127	125	90	4-φ19
	1 1/4"	32	140	135	100	4-φ19
	1 1/2"	40	165	140	105	4-φ19
	2"	50	178	155	120	4-φ19
	2 1/2"	65	190	175	140	4-φ19
	3"	80	203	185	150	8-φ19
	4"	100	229	210	175	8-φ19
	5"	125	356	250	210	8-φ23
	6"	150	394	280	240	8-φ23
	8"	200	457	330	290	12-φ23
	10"	250	533	400	355	12-φ25
	12"	300	610	445	400	16-φ25
