ansi stainless steel globe valves

the release date：[2017-08-07] hits

american standard cut valve features: feature
1. streamlined, with rod with bracket 1.streamline outside screw and yoke
2. middle flange bolted 2.bolted bonnet
3. sleeve connection valve 3.loose disc
4. lifting valve stem hand wheel 4.rising stem and hand wheel
5. bracket and bonnet integrated 5.yoke integral with bonnet
6. bevel gear operation optional 6.avail able with gear operator
7. standard flange connection 7.flanged ends
american standard method specification for blue stop valve product specification

standard specification for stainless steel american standard cut - off valves

product specification

product

specification

design spec

structure length face to face

flange end flange end

test & inspection

pressure - temperature pressure-temp

product identification

supply specification

supply

asme b16.34

ansib 16.10

ansib 16.5

api598

asme b 16.34

mss sp-25

asme b16.34

bs 5160

american standard flange stop valve main parts material main part material

part name	part material				part name
body / bonnet	a216-wcb	a217-wc6	a352-lcb	a351-cf8m	body / bonnet
valve	a105	a182-f11	a182-f304	a182-f316	disk
stem	a182-f6a	a182-f11	a182-f6a	a182-f316	stem
填料	柔性石墨/ flexible graphite			聚四氟乙烯/ptfe	packing
垫片	18-8柔性石墨/18-8flexible graphite				gasket
螺栓	a193-b7	a193-b7	a193-b7m	a193-b8	bolt
适用温度	-29~425℃	-29~550℃	-46~350℃	-40~200℃	suitable temp
适用介质	水，油品，蒸汽 water，oil，steam	蒸汽，油品 steam，oil	丙烷，乙烯 propane，ethane	硝酸类 nitric acid	suitable medium

美标法兰截止阀主要外形和连接尺寸main external and connectio

美标法兰截止阀尺寸列表dimension list

产品型号 type	nps	dn	class 150lb								wt（kg）
产品型号 type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
j41h-150lb j41w-150lbp j41y-150lbp j41y-150lbr j41y-150lbpl j41y-150lbrl	1/2"	15	108	89	60.5	35	10	4-φ15	169	125	5.0
	3/4"	20	117	98	70	43	11	4-φ15	180	125	7.0
	1"	25	127	108	79.5	51	12	4-φ15	190	125	9.0
	11/4"	32	140	117	89	63	13	4-φ15		160
	11/2"	40	165	127	98.5	73	14.3	4-φ16	347	180	15.0
	2"	50	203	152	120.5	92	15.9	4-φ19	356	180	18
	21/2"	65	216	178	139.5	105	17.5	4-φ19	381	240	30
	3"	80	241	190	152.5	127	19.1	4-φ19	411	280	41
	4"	100	292	229	190.5	157	24	8-φ19	454	280	64
	5"	125	356	254	216	186	24	8-φ22	541	320	86
	6"	150	406	279	241.5	216	25.4	8-φ22	656	360	113
	8"	200	495	343	298.5	270	29	8-φ22	800	450	115
	10"	250	622	406	362	324	31	12-φ25	1231	500	295
	12"	300	698	483	432	381	32	12-φ25	1450	600	450

美标法兰截止阀尺寸列表dimension list

产品型号type	nps	dn	class 300lb								wt（kg）
产品型号type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
j41h-300lb j41w-300lbp j41y-300lbp j41y-300lbr j41y-300lbpl j41y-300lbrl	1/2"	15	152	95	66.5	35	15	4-φ15	241	125	5.2
	3/4"	20	178	117	82.5	43	16	4-φ19	241	125	7.3
	1"	25	203	124	89	51	18	4-φ19	283	160	9.5
	11/4"	32	216	133	98.5	63	19	4-φ19	320	200
	11/2"	40	229	156	114.3	73	21	4-φ22	322	200	17.6
	2"	50	267	165	127	92	23	8-φ19	399	200	25
	21/2"	65	292	190	149	105	26	8-φ22	438	250	30
	3"	80	318	210	168.5	127	29	8-φ22	464	280	35
	4"	100	356	254	200	157	32	8-φ22	565	355	56
	5"	125	400	279	235	186	35	8-φ22	614	400	96
	6"	150	444	318	270	216	37	12-φ22	717	450	120
	8"	200	559	381	330	270	42	12-φ25	930	500	212
	10"	250	622	444	387.5	324	48	16-φ29	1012	500	460
	12"	300	711	521	451	381	51	16-φ32	1231	600	615
