din3230 high mounting pad ball valve

the release date:[2017-09-16]     hits

din high mounting pad ball valve material(apirt valve)

apirt valve·zhejiang ruitong valve co.,ltd·features:
apirt valve·face to face dimensions:din 3357 en 12516-1
apirt valve·end flanged imensions:din en 1092-1

apirt valve·design:din3230

apirt valve·test:din3230,en12266
apirt valve·investment casting body
apirt valve·lever operated with eirect
apirt valve·mounting pad

shell (by water)pn1.6mpa32kg/c ㎡seatby water315psi22 kg/c ㎡by air80psi6 kg/c ㎡


din flanged ball valve fac to fae
l:mm
sizepndlrcdhh1eft□pø aøbnøxiso 5211
dn1510-4015115456595783415021411424414f04
dn2010-40201205875105803515021611424414f04
dn2510-40251256885115884515021611424414f04
dn3210-4032130781001401005017021614505418f05
dn4010-4038140881101501226023031617706418f07
dn5010-40501501021251651306823031817706418f07
dn6510-16651701221451851488623031817706418f07
dn8010-167818013816020016796305320221028818f10
dn10010-16100190158180220188117305320221028818f10
dn12510-161253251882102502461415003222212510818f12
dn15010-161503502122402852881726503222712510822f12
dn20010-1620040026829534032921385032427125101222f12
dn25010-16250450320355405396255140032636140141226f14
