american standard bevel gear gate valve -ag旗舰厅首页

quick details

type:

gate valves

place of origin:

zhejiang, china

brand name:

apirt

model number:

z41h-150lb z40h-300lb z40h-600lb

application:

general

temperature of media:

medium temperature

power:

manual

media:

oil

port size:

1/2"~24"

structure:

shutoff

standard or nonstandard:

standard

size:

8inch

product name:

gate valve

body material:

wcb

standard:

asme

connection:

flange ends

certificate:

api 6d

color:

silver

name:

a216 gate valve

medium:

water oil gas

packaging & delivery

selling units:

single item

single package size:

45x55x65 cm

single gross weight:

20.000 kg

package type:

plywood cases

api gate valve

picture example:

lead time :

video description

product description

api6d gate valve,6d flanged gate valve,apirt api6d flanged gate valve

api flanged gate valve product characteristics:

1.the design of products production matches a foreign forerunner standard request, seal completely firm, the performance is good.

2.the structure designs tightly packed reasonable, shape beauty

3.adopt wedge type flexible sluice board structure, establish to roll over bearing amid the big caliber, the qi shuts easily.

4.the valve body material species is well-found, the filling compound, packing sheet slab chooses to go together with according to the actual work condition or the consumer request reasonable, applicably at the various press, temperature and dielectric work condition.

5.the adoption various pipe arrangement law orchid standards and law orchid seal completely surface pattern at home and abroad and satisfy various engineering requirement and consumer's request

api6d gate valve,6d flanged gate valve,apirt api6d flanged gate valve

specification of api 6d gate valve :

size:1/2"-24"

pressure:150lb~1500lb

material: wcb, wcc, lcb, lcc, wc6, wc9, c5, c12, cf8, cf8m, cf3, cf3m, cf8c, cn7m,etc.

type: rising stem,bb,fb,os&y

operation: hand wheel. gear, electricty, etc.

api6d gate valve,6d flanged gate valve,apirt api6d flanged gate valve

full port design, os&y, outside and screw, bolted bonnet, back seal structure

flexible wedge, fully guided, choice of solid or split wedge

welded seat

extended stem design for low temperature

flanged or butt-welding end

standard of api 6d gate valve :

design and manufacture: api 600, api 6d, bs1414,etc

face to face (end to end): ansi b16.10, api 6d,etc

flanged connection: ansi b16.5,etc

butt welded end: ansi b16.25,etc

est and inspection: api 598, api 6d,etc

products show-api 6d

our service-api 6d

api gate valve

the structure designs tightly packed reasonable, shape beauty.

high quality

position by the valve stem threads are divided into clear shot valve and the dark bar gate two. this type valve in the pipe should normally be installed horizontally.

high quality

api gate valve : inspection and test: api 598

our company-api 6d

factory

our factory

workshop

our workshop

warehouse

our warehouse-api6d gate valve

team

contact us:api 6d gate valve

our certifications

professional manufacture for api valves;

our products are widely recognized and trusted by users and can meet continuously developing economic and social needs. we welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!

packing & delivery

packing details : use plywood case to package all valves.

delivery details : 3-30 days after order of api flanged gate valve

ruitong packing

we psusuit every detail perfect,casting high quality valves.the handle wheel is epoxy coating spray paint.the gate valve handle.use plywood case to package all api gate valves.

favorable comment

ruitong valve is one of the professional gate valve manufacturer in china.. we supplies :cast steel gate valve、forged steel gate valve, resilient seated gate valve, flanged end gate valve etc, we can manufacture and supply gate valves according to your requirements, please contact us !

favorable comment

with a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in petroleum, chemical industry, metallurgy, electric power, pharmaceutical, paper, urban construction and other industries.

faq

q: are you trading company or manufacturer ?

a: we are factory.

q: how long is your delivery time?

a: generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

q: do you provide samples ? is it free or extra ?

a: yes, we could offer the sample for free charge but do not pay the cost of freight.

q: what is your terms of payment ?

a: payment

if you have another question, pls feel free to contact us as below:
